RUSHFPV Cherry 5.8GHz Antenna w/ Extended Length Locking U.FL - Choose Polarization

This antenna is designed specifically for FPV drones with the need for a little more length in your antenna wire, offering a wide 5.6-6GHz bandwidth that covers all channels of the raceband with consistent transmission strength. It also provides a perfect circular polarization axis ratio, reducing screen flicker caused by multi-path interference.

The Rush FPV Cherry antenna is made to be small and sturdy, with a flexible tube that can withstand impact and angle bends to prevent cable damage. It uses a thin Teflon skin, double shielded coaxial cable with a silver-plated core that is soft, flexible, and has low signal loss. Additionally, it has a VSWR below 1.2 between 5650 and 5950MHz, ensuring transmission efficiency of up to 98% and reducing VTX heat.

Installation is quick and easy, using antenna clips that match the standard UF.L socket. Quality assurance is guaranteed, as each antenna is tuned for performance by the Rush FPV Professional Microwave Laboratory and qualified by a network analyzer before leaving the factory.

SPECIFICATIONS:

• Gain: 1.2dBi
• S11 SWR: 1.4 max - 1.1 min
• Band Width: 5600-6000-MHz
• Axial Ratio: Around 1.0
• Length: ~155mm
• Polarization: LHCP or RHCP
• Designed by TrueRC
• Manufactured by Lumenier
• Connector: New designed UFL lock - pull the metal slot out so it releases and put the antenna, slot it back for lock

INCLUDES:

• 2 x Rush FPV Cherry 5.8GHz Extended Edition Locking U.FL Antenna
• Mounts and Screws
