Tattu Semi-Solid State 300Wh/kg 17000mAh 10C 22.2V 6S1P G-Tech Lipo Battery Pack with XT90S-F

Tattu Semi-Solid State 300Wh/kg 17000mAh 10C 22.2V 6S1P G-Tech Lipo Battery

The Tattu Semi-solid state 300Wh/kg 17000mAh 22.2V 10C 6S1P G-Tech Lipo Battery is a revolutionary semi-solid lithium battery, featuring high energy density and long service life.

Compared with traditional lithium batteries, Tattu Semi-solid State battery has a higher energy and lighter weight, can increase the battery endurance by 30% and cycle life more than of 500 cycles (90% initial capacity). It is an ideal power solution for various industrial drones, including those used in mapping, inspection, surveying, delivery, and eVTOL applications.

Battery Specifications

• Capacity: 17000mAh
• Voltage: 22.2V / 6S
• Max Peak Current: 10C
• Max Constant Discharge: 3C continuous
• Net Weight: 1432g (±20g)
• Size: 193 × 71 × 50.5mm
• Discharge Connector: XT90S-F
• Balancer Connector: G-Tech-7P
• Discharge Wire: 8# 150mm
• Charge Wire: 22# 65mm

Features

• Energy Density: 300Wh/kg – Ultra-lightweight for maximum flight time
• Safety Performance: Voltage range 4.2V to 2.75V (SOC 100% to 0%)
• Discharge Rate: Max constant 3C, peak 5C (< 3 seconds)
• Cycle Life: Over 500 cycles at 90% initial capacity
• G-Tech Compatible: Works with Tattu TA1000 charger for automatic current allocation

Technical Features

• Ultra-High Nickel Technology: Higher energy density and performance
• Silicon Carbon Anode: Enhanced capacity and cycling stability
• Coated Diaphragm Technology: Improved safety and separator strength
• Solid Electrolyte: Reduced leakage risk and longer life

Our Advantage

• Orders dispatched via FedEx from the USA
• Fast shipping with local after-sale service in the USA
• 90-day warranty on all batteries
• Low IR for stable voltage throughout the entire mission
• ISO9001 and ISO14001 certified safety standards
